Applications
For suction of light industrial debris and dust.
Suitable for conveying small particles and moderately abrasive materials.
Advantages
Very light weight and easy to handle.
Excellent bending radius and flexibility.
Very good crush resistance.
Design
Technical drawing
Overview
Inner tube
wear resistant NR, smooth, beige,
Reinforcement
synthetic textile, cords, with embedded steel helix,
Cover
rubber coated fabric, corrugated, white,
Temperature range
-30 to +70
Technical Specifications
| ID (mm) | Wall thickness (mm) | OD (mm) | Working Pressure (bar) | Bursting pressure (bar) | Max. vacuum (bar) | Bending radius (mm) | Weight (kg/m) | Length (m) | Article number | Stock or min. order (m) |
¤ Upon availability. * Tolerance on length: ± 1 % (ISO 1307 Standard)
