For DRY : polyamide film.
For WET : nylon and PTFE film.
Applications
Suction and discharge for light or heavy petroleum products and derivatives with aromatic content up to 100%. Specilly designed for bio-diesel products. Also suitable for Jet A1, AVGAS, and kerosene.
Advantages
- Capable of handling solvents.
- Easy handling due to hose flexibility (low bending radius).
- Electrical conductivity ensured by the two helices.
Design
Overview
Inner tube
Reinforcement
For DRY : polypropylene and polyamide layers.
For WET : nylon and PTFE layers.
For WET : nylon and PTFE layers.
Cover
For DRY : PVC coated fabric, corrugated.
For WET : PET and PVC coated fabric, corrugated.
For WET : PET and PVC coated fabric, corrugated.
Temperature range
-30 to +100
Standard/Approval
All types of crimped couplings available.
2 Types of sealing :
- DRY sealing for the standard range from 25 to 100mm.
- WET sealing for the premium range from 100 to 300mm, improving reliability, durability and safety.
2 Types of sealing :
- DRY sealing for the standard range from 25 to 100mm.
- WET sealing for the premium range from 100 to 300mm, improving reliability, durability and safety.
Additional information
Fitted lengths are delivered on request with pressure test certificate.
On request :
- Light duty type 1 (7 bar) and Standard duty type 2 (10.5 bar).
- Wet sealing for smaller diameter.
- Other inner and outer helix qualities.
- Other cover colors.
- Imperial size.
Max. vacuum: 0.9 bar.
On request :
- Light duty type 1 (7 bar) and Standard duty type 2 (10.5 bar).
- Wet sealing for smaller diameter.
- Other inner and outer helix qualities.
- Other cover colors.
- Imperial size.
Max. vacuum: 0.9 bar.
Technical Specifications
| ID (mm) | OD (mm) | Working Pressure (bar) | Bursting pressure (bar) | Max. vacuum (bar) | Bending radius (mm) | Weight (kg/m) | Length (m) | Article number |
¤ Upon availability. * Tolerance on length: ± 1 % (ISO 1307 Standard)
