Applications

Advantages

Design

Overview
Inner tube
EPDM, smooth, black,
Reinforcement
steel, braided,
Cover
CSM, fabric impression, red,
Temperature range
, Water: -40°C to +120°C, WP=60bar.
Saturated steam: +210°C/18bar.
Superheated steam: +230°C/18bar
Electrical properties
conductive tube, R<10^6Ω/lg.
Standard/Approval
ISO 6134:2017 type 2 class B.
Technical Specifications
ID (mm) Wall thickness (mm) OD (mm) Working Pressure (bar) Bursting pressure (bar) Max. vacuum (bar) Bending radius (mm) Weight (kg/m) Length (m) Article number Stock or min. order (m)
¤ Upon availability.
* Tolerance on length: ± 1 % (ISO 1307 Standard)
Pressure Table
Notes
