Applications
For cleaning and shot blasting castings, metal, stone and concrete surfaces.
Advantages
Small tolerances, therefore easy to couple.
Longitudinally stable i.e. the length will not alter under pressure (unstable hoses result in the operator losing control when pressure is applied).
Light weight and flexible for easy handling.
Conductive inner tube compound gives increased safety for the operator, since there is no risk of wire breakage in use.
Design
Technical drawing
Overview
Inner tube
wear resistant NR, smooth, black,
Reinforcement
synthetic textile,
Cover
wear and weather resistant SBR, fabric impression, black,
Temperature range
-30 to +70
Electrical properties
conductive tube, R<2.10^6Ω/m.
Special properties
abrasion resistance of tube <40mm3 according to ISO 4649.
Technical Specifications
| ID (mm) | Wall thickness (mm) | OD (mm) | Working Pressure (bar) | Bursting pressure (bar) | Max. vacuum (bar) | Bending radius (mm) | Weight (kg/m) | Length (m) | Article number | Stock or min. order (m) |
¤ Upon availability. * Tolerance on length: ± 1 % (ISO 1307 Standard)
