Applications
Designed to meet the requirements of the wine and brewing industries, this product ensures the safe transfer of wine and beer, while providing high resistance to accidental crushing.
Suction and discharge of other liquid foodstuffs such as milk, cider, fruit juice, and alcohol up to 50%, except fatty products.
Advantages
- A smooth, seamless, white, multipurpose food grade tube that does not propagate bacterial growth.
- Collapsible: will recover its shape after accidental squeeze.
- Flexible and easy to handle.
- Excellent resistance to kinking.
- Changes in temperature have little effect due to the qualities of the rubber compound.
- Resistant to cleaning with most common detergents (see our cleaning guideline for details) or with steam at max. 130°C.
- Non-marking, abrasion-resistant cover.
- Contains no phthalate.
Design
Technical drawing
Overview
Inner tube
food grade EPDM, white, smooth.
Reinforcement
synthetic textile with embedded PET helix.
Cover
weather resistant EPDM, red, fabric impression.
Temperature range
-30 to +100
Standard/Approval
Specially designed fittings are available, please contact us for further information in order to get optimum connections.
Additional information
Please refer to our cleaning guidelines, available upon request and from our website.
Technical Specifications
| ID (mm) | OD (mm) | Working Pressure (bar) | Bursting pressure (bar) | Max. vacuum (bar) | Bending radius (mm) | Weight (kg/m) | Length (m) | Article number |
¤ Upon availability. * Tolerance on length: ± 1 % (ISO 1307 Standard)
