Applications
Specially designed for professional and industrial high pressure cleaning.
Efficient for machines, vehicles, floors, public areas, facades, etc.
The non-staining cover is also an advantage for use in food industry and public baths.
Suitable for mobile pressure washers, fixed installations and reel mounted applications.
Advantages
Non-staining smooth cover.
Oil, detergent, wear and weather resistant.
High temperature resistance.
Light weight, flexible and kink resistant.
Long service life.
Design
Technical drawing
Overview
Inner tube
NBR/SBR, black, smooth.
Reinforcement
steel
Cover
SBR/NBR, blue, smooth.
Temperature range
-40 to +150
Standard/Approval
Specially designed fittings are available, please contact us for further information in order to get optimum connections.
Additional information
50% of the volume in each delivery will be random lengths, shortest length of 10m, at least 50% will be in fixed length mentioned in the table.
Technical Specifications
| ID (mm) | OD (mm) | Working Pressure (bar) | Bursting pressure (bar) | Max. vacuum (bar) | Bending radius (mm) | Weight (kg/m) | Length (m) | Article number |
¤ Upon availability. * Tolerance on length: ± 1 % (ISO 1307 Standard)
