MC 25
MC 25 will lead through and seal cables as follows:
2 x 3mm - 11mm
5 x 10mm - 14mm
12 x 14mm - 18mm
5 x 14mm - 22mm
1 x 14mm - 35mm
Total of 25 cables
![PR_MC-35_Grey](/anti-vibration-solutions/-/media/anti-vibration-systems_tis/ces-portfolio/cable-entry-plates/mc/pr_mc-35_grey.jpg?rev=764bd902249e4f5da8922f505d1a5ce7&w=800&hash=961F8060F303E4FA6C1A4F61528FE0F4)
MC 35
MC 35 will lead through and seal cables as follows:
2 x 6mm - 10mm
14 x 7mm - 12mm
16 x 10mm - 14mm
2 x 12mm - 18mm
1 x 17mm - 32mm
Total of 35 cables
![PR_MH10-F-12-1_Grey](/anti-vibration-solutions/-/media/anti-vibration-systems_tis/ces-portfolio/cable-entry-plates/mh/pr_mh10-f-12-1_grey.jpg?rev=3eefc75894a44e4f85128bb6c0913f04&w=800&hash=6BE449225716284ACAE8B4E4374019E7)
MH 10
MH 10 will lead through and seal cables as follows:
5 x 3mm - 7mm
4 x 5mm - 10mm
2 x 7mm - 13mm
1 x 9mm - 16mm
Total of 12 cables
![PR_MH16-F-17-1_Grey](/anti-vibration-solutions/-/media/anti-vibration-systems_tis/ces-portfolio/cable-entry-plates/mh/pr_mh16-f-17-1_grey.jpg?rev=e08dd66e1ff1473c8b22ad3ac518d992&w=800&hash=7D23337C21ACE3C62B0A67C7A4E5608C)
MH 16
MH 16 will lead through and seal cables as follows:
12 x 3mm - 7mm
5 x 7mm - 13mm
Total of 17 cables
![PR_MH24-F-17-2_Grey](/anti-vibration-solutions/-/media/anti-vibration-systems_tis/ces-portfolio/cable-entry-plates/mh/pr_mh24-f-17-2_grey.jpg?rev=a7d2cac0d7e948fb92985e5a469d54fd&w=800&hash=DF572FA1F3A87BBEADBA70DA302830E4)
MH 24
MH 24 will lead through and seal cables as follows:
6 x 3mm - 7mm
6 x 5mm - 10mm
5 x 9mm - 16mm
Total of 17 cables
![PR_RMC-17_Grey](/anti-vibration-solutions/-/media/anti-vibration-systems_tis/ces-portfolio/cable-entry-plates/rmc/pr_rmc-17_grey.jpg?rev=c004ab917e464470a72a7707969de137&w=800&hash=6D778A3016929925069719F096861958)
RMC 17
RMC 17 will lead through and seal cables as follows:
4 x 5mm - 7mm
2 x 10mm - 12mm
2 x 12mm - 15mm
9 x 10mm - 30mm
Total of 17 cables
![PR_MC-3_Grey](/anti-vibration-solutions/-/media/anti-vibration-systems_tis/ces-portfolio/cable-entry-plates/mc/pr_mc-3_grey.jpg?rev=cf5e1cea226c4b44abe3356b84d6ca1e&w=800&hash=9B4D0C101F979D8A90AABCD92408CA6F)
MC 3
MC 3 will lead trough and seal cables as follows:
4 x 8mm - 12mm
2 x 24mm - 54mm
1 x 30mm - 60mm
Total of 7 cables
Description | Width (A) mm |
Lenght (B) mm |
Height (C) mm |
Dept 1 (D) mm |
Dept 2 (E) mm |
---|---|---|---|---|---|
MC 3 |
214 |
82 |
40 | 19 | 27 |
MC 25 | 216 | 84 | 27 | 15 | 21 |
MC 35 | 216 | 84 | 31 | 17 | 22 |
MH 10 | 107 | 56 | 19 | 9 | 19 |
MH 16 | 127 | 56 | 19 | 9 | 19 |
MH 24 | 154 | 56 | 19 | 9 | 19 |
RMC 17 | 220 | 88 | 26 | 26 | 10 |
Description | Aperture | Part no | Colour | RAL code | Feature | No of cables |
---|---|---|---|---|---|---|
MC 3 |
C opening (FL21) |
100234 |
Light grey | 7035 | 7 | |
MC 3 | C opening (FL21 |
100235 | Black | UL94V-0 | 7 | |
MC 3 | C opening (FL21 |
100233 | Grey | 7032 | 7 | |
MC 3 | C opening (FL21) | 100931 | Black | EMC |
7 | |
MC 25 | C opening (FL21) |
100238 | Light grey | 7035 | 25 | |
MC 25 | C opening (FL21) |
100239 | Black | UL94V-0 | 25 | |
MC 25 | C opening (FL21) |
100237 | Grey | 7032 | 25 | |
MC 25 | C opening (FL21) | 100214 | Black | EMC | 25 | |
MC 35 | C opening (FL21) |
100244 | Light grey | 7035 | 35 | |
MC 35 | C opening (FL21) |
100245 | Black | UL94V-0 | 35 | |
MC 35 | C opening (FL21) | 100243 | Grey | 7032 | 35 | |
MC 35 | C opening (FL21) | 100215 | Black | UL94V-0 | 35 | |
MH 10 | B10 | 107293 | Black | UL94V-0 | 12 | |
MH 10 | B10 | 107294 | Light Grey | 7035 | UL94V-0 | 12 |
MH 16 | B16 | 107292 | Black | UL94V-0 | 17 | |
MH 16 | B16 | 107295 | Light Grey | 7035 | UL94V-0 | 17 |
MH 24 | B24 | 107291 | Black | UL94V-0 | 17 | |
MH 24 | B24 | 107296 | Light Grey | 7035 | UL94V-0 | 17 |
RMC 17 | C opening (FL21) | 106998 | Black | UL94V-0 | 17 | |
RMC 17 | C opening (FL21) | 108424 | Light Grey | 7035 | UL94V-0 | 17 |
