Applications
Suction and discharge of light and heavy hydrocarbons and
derivatives with aromatic content up to 100%.
Road, rail and stationary equipment.
Advantages
Easy-to-handle flexible hose (small bending radius).
Can be used in all temperatures.
Design
Overview
Inner tube
Polypropylene
Reinforcement
Plastic sheets and films
Cover
PVC-coated fabric.
Temperature range
-30 to +115
Standard/Approval
Possible connection types:
1/2 symmetrical (aluminum, bronze, stainless steel) ;
BSP male, swivel-head female ;
Camlock quick-connect coupling.
Fixed or rotating flanges (ISO PN 10/16, ASA 150).
1/2 symmetrical (aluminum, bronze, stainless steel) ;
BSP male, swivel-head female ;
Camlock quick-connect coupling.
Fixed or rotating flanges (ISO PN 10/16, ASA 150).
Technical Specifications
| ID (mm) | OD (mm) | Working Pressure (bar) | Bursting pressure (bar) | Max. vacuum (bar) | Bending radius (mm) | Weight (kg/m) | Length (m) | Article number |
¤ Upon availability. * Tolerance on length: ± 1 % (ISO 1307 Standard)
