Applications
Hydraulic suction and discharge of abrasive products.
Design

Overview
Inner tube
wear resistant NR, black, smooth.
Reinforcement
synthetic textile with embedded steel helix
Cover
wear resistant NR/SBR, black, smooth fabric impression.
Temperature range
-30 to +70
Standard/Approval
Special half shelves coupling.
Technical Specifications
ID (mm) | OD (mm) | Working Pressure (bar) | Bursting pressure (bar) | Max. vacuum (bar) | Bending radius (mm) | Weight (kg/m) | Length (m) | Article number |
¤ Upon availability. * Tolerance on length: ± 1 % (ISO 1307 Standard)
