Applications
Discharge of petroleum products, especially designed for applications on reels.
Road tanker equipment for oil delivery (aromatic content up to 50%).
Advantages
- Hose can be cut to length as required.
- Cover especially designed for oil, abrasion and weather resistance.
- Electrical conductivity ensured by the tube compound.
- In compliance with chemicals industry requirements.
- Suitable for biofuels up to 60°C.
Design
Technical drawing
Overview
Inner tube
oil and petrol resistant NBR, black, smooth.
Reinforcement
synthetic textile
Cover
oil and weather resistant CR, black, fabric impression.
Temperature range
-40 to +100
Additional information
ID>100mm: not included in EN 1761 and EN 12115 but designed, made and tested according to the same specifications required by both standards.
Technical Specifications
| ID (mm) | OD (mm) | Working Pressure (bar) | Bursting pressure (bar) | Max. vacuum (bar) | Bending radius (mm) | Weight (kg/m) | Length (m) | Article number |
¤ Upon availability. * Tolerance on length: ± 1 % (ISO 1307 Standard)
